Brand Name : | SMX |
Model Number : | MX-VL820U |
Certification : | RoHS&CE |
Price : | negotiation |
Payment Terms : | L/C, T/T, Western Union, MoneyGram |
Supply Ability : | 1000 Piece/Pieces Per Month |
Delivery Time : | 10 work days |
2024 new 8200 lumen outdoor video ANSI Native laser tv Active 3D projector
Features
◆ 3LCD tech, 30,000 hours Led Lamp of real life time
◆ High brightness 8200 Lumens
◆ High contrast (5000000:1)
◆ Multiple Interfaces (HDMI, USB-A, HD BaseT, VGA, 3.5mm, RS232, RJ45, USB-B)
◆ V&H:±30°/Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction/Grid image tune
◆ Optional Resolution: WUXGA/WXGA/XGA, all support 4K
◆ Aspect ratio: 16:9/16:10/4:3
◆ Support Mirror&Wireless&Airplay etc.
◆ Best picture quality
◆ 360° projection
Physical Display
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model | MX-VL703Y | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness | Brightness (Ansi Lumens) | 7000 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Overall Spec | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panel | Display Panel | 3x0.64” with MLA | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Technology | Liquid Crystal Display | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Native Resolution | WUXGA (1920 x 1200) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Light source Life time | FullNormal/Normal Model | 20000hrs | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ECO1 Mode | 30000hrs | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ECO2 Mode | 30000hrs | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Projection Lens | Lens Vendor | RICOH Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
F | 1.5~2.08 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
f | 17.2~27.7mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Zoom/Focus | Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Throw Ratio | 1.2(wide)-2.0(tele) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Zoom Ratio | 1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Size | 30-300 inch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Shift | V:+60%~0%, H:±29% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
CR | Contrast Ratio (FOFO) | 5000000:1 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise | Noise(dB) | 38dB(Normal) 30dB(ECO1) 28dB(ECO2) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Uniformity | Uniformity(Actual Min) -JISX6911 | 80% | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
AR | Aspect Ratio | Native:16:10 Compatible: 4:3/16:9 |
![]() |
