| Specification for 6500 Lumen Laser Projector | | Model | MX-VL650U | | Brightness | Brightness
(Ansi Lumens) | 6500 | | Overall Spec | | | | Panel | Display Panel | 3x0.64” with MLA | | Display Technology | Liquid Crystal Display | | Native Resolution | WUXGA (1920 x 1200) | Light source
Life time | FullNormal/Normal Model | 20000hrs | | ECO1 Mode | 30000hrs | | ECO2 Mode | 30000hrs | Projection
Lens | Lens Vendor | RICOH Lens | | F | 1.5~2.08 | | f | 17.2~27.7mm | | Zoom/Focus | Manual | | Throw Ratio | 1.2(wide)-2.0(tele) | | Zoom Ratio | 1.6 | | Screen Size | 30-300 inch | | Lens Shift | V:＋60%～0%,
H:±29% | | CR | Contrast Ratio
(FOFO) | 5000000:1 | | Noise | Noise(dB) | 38dB(Normal)
30dB(ECO1)
28dB(ECO2) | | Uniformity | Uniformity(Actual Min)
-JISX6911 | 80% | | AR | Aspect Ratio | Native:16:10
Compatible: 4:3/16:9 | | Terminal(I/O port) | | | | Input | VGA | *1 | | HDMI 1.4B(IN) | *2 | | USB-A | *1 | | USB-B | *1(Display) | | RJ45 | *1(Display) | | DVI-D | N/A | | HD BaseT | *1(Optional) | | HD-SDI(3G-SDI) | N/A | | Video | N/A | Audio in
(mini jack,3.5mm) | *1 | | Output | VGA | *1 | | HDMI 1.4B(OUT) | N/A | Audio out
(mini-jack,3.5mm) | *1 | | Control | RS232 | *1 | | RJ45 | *1 (Control) | | USB-B | *1 (For upgrade) | | Wired Remote(IN) | N/A | | Wired Remote(OUT) | N/A | | General Spec | | | | Audio | Speaker | 16W*1 | | Dust filter | W/Filter | | Filter Life time | 8000h | Power
Consumption | Power Requeirements | 100~240V@ 50/60Hz | Power Consumption
(Normal) (Max) | 360 | Power Consumption
(ECO1) (Max) | 280 | Power Consumption
(ECO2) (Max) | 230 | ECO Standby Mode
Power Consumption | <0.5W | | Temp.&Humidity | Operation Temp. | 0 to 40°C | | Operation Thumidity. | 20-85% | | Store Temp. | -10 to 50°C | | High Altitude | 0~3000m | | Other Functions | | | | Keystone | Keyston Correction
(Lens@center) | V: ±30°
H:±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
4 Corner Correction
Grid image tune | | OSD | Languages | 26 languages:
English, German, French, Italian, Spanish, Polish, Swedish, Dutch
,Portugese, Japanese, Simplified Chinese, Traditional Chinese,
Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish,
Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi | | LAN Control | LAN Control-RoomView
(Crestron) | Yes | LAN Control-
AMX Discovery | Yes | LAN Control-
PJ Link | Yes | Scanning
Frequency | H-Synch Range | 15~100KHz | | V-Synch Range | 24~85Hz | Display
Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz | | Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i and 1080p | | SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto Keystone | | Blank | Yes | | Suspend | Yes(5miniutes no singnal as default) | | Picture Model | Dynamic, Standard, Cinema,
Colorboard, sim-DICOM ,Blackboard(Green) | | Cooling Time | OS,normal,30s | | Closed Caption | N/A | | Auto Ceiling | Yes | | D-Zoom | 1~33 | | Others | 360° Projection | Yes | | Edge Blending | N/A | Wireless display
(Optional function) | SmartPhone:
Android:Install APK for Android
iphone: Airplay function
PC Wireless Display:
Support WiFi Display@Windows&MAC system
through dongle | | Dimension&Weight | | | | | MAX Dimensions
(WxDxH mm) | 405 (W)*358(D)*137(H) | Net Weight
(KG) | ~7.9 | | | Packaging Box Dimensions
(WxDxH mm) | 510 (W)*498(D)*260(H) | Gross.Weight
(KG) | ~10.4 | | Accessory | | | | | Manual Languages | Chinese,English | | Standard Accessaries | Power cord(EU) /power cord(Ja)
Remote control&RC Battery |
| |
