| Model | MX-VL650U |
| Brightness | Brightness
(Ansi Lumens) | 6500 |
| Overall Spec | | |
| Panel | Display Panel | 3x0.64” with MLA |
| Display Technology | Liquid Crystal Display |
| Native Resolution | WUXGA (1920 x 1200) |
Light source
Life time | FullNormal/Normal Model | 20000hrs |
| ECO1 Mode | 30000hrs |
| ECO2 Mode | 30000hrs |
Projection
Lens | Lens Vendor | RICOH Lens |
| F | 1.5~2.08 |
| f | 17.2~27.7mm |
| Zoom/Focus | Manual |
| Throw Ratio | 1.2(wide)-2.0(tele) |
| Zoom Ratio | 1.6 |
| Screen Size | 30-300 inch |
| Lens Shift | V:＋60%～0%,
H:±29% |
| CR | Contrast Ratio
(FOFO) | 5000000:1 |
| Noise | Noise(dB) | 38dB(Normal)
30dB(ECO1)
28dB(ECO2) |
| Uniformity | Uniformity(Actual Min)
-JISX6911 | 80% |
| AR | Aspect Ratio | Native:16:10
Compatible: 4:3/16:9 |
| Terminal(I/O port) | | |
| Input | VGA | *1 |
| HDMI 1.4B(IN) | *2 |
| USB-A | *1 |
| USB-B | *1(Display) |
| RJ45 | *1(Display) |
| DVI-D | N/A |
| HD BaseT | *1(Optional) |
| HD-SDI(3G-SDI) | N/A |
| Video | N/A |
Audio in
(mini jack,3.5mm) | *1 |
| Output | VGA | *1 |
| HDMI 1.4B(OUT) | N/A |
Audio out
(mini-jack,3.5mm) | *1 |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) |
| USB-B | *1 (For upgrade) |
| Wired Remote(IN) | N/A |
| Wired Remote(OUT) | N/A |
| General Spec | | |
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter |
| Filter Life time | 8000h |
Power
Consumption | Power Requeirements | 100~240V@ 50/60Hz |
Power Consumption
(Normal) (Max) | 360 |
Power Consumption
(ECO1) (Max) | 280 |
Power Consumption
(ECO2) (Max) | 230 |
ECO Standby Mode
Power Consumption | <0.5W |
| Temp.&Humidity | Operation Temp. | 0 to 40°C |
| Operation Thumidity. | 20-85% |
| Store Temp. | -10 to 50°C |
| High Altitude | 0~3000m |
| Other Functions | | |
| Keystone | Keyston Correction
(Lens@center) | V: ±30°
H:±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
4 Corner Correction
Grid image tune |
| OSD | Languages | 26 languages:
English, German, French, Italian, Spanish, Polish, Swedish, Dutch
,Portugese, Japanese, Simplified Chinese, Traditional Chinese,
Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish,
Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi |
| LAN Control | LAN Control-RoomView
(Crestron) | Yes |
LAN Control-
AMX Discovery | Yes |
LAN Control-
PJ Link | Yes |
Scanning
Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 24~85Hz |
Display
Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i and 1080p |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC,Auto Keystone |
| Blank | Yes |
| Suspend | Yes(5miniutes no singnal as default) |
| Picture Model | Dynamic, Standard, Cinema,
Colorboard, sim-DICOM ,Blackboard(Green) |
| Cooling Time | 0s,normal,30s |
| Closed Caption | N/A |
| Auto Ceiling | Yes |
| D-Zoom | 1~33 |
| Others | 360° Projection | Yes |
| Edge Blending | N/A |
Wireless display
(Optional function) | SmartPhone:
Android:Install APK for Android
iphone: Airplay function
PC Wireless Display:
Support WiFi Display@Windows&MAC system
through dongle |
| Dimension&Weight | | |
| | MAX Dimensions
(WxDxH mm) | 405 (W)*358(D)*137(H) |
Net Weight
(KG) | ~7.9 |
| | Packaging Box Dimensions
(WxDxH mm) | 510 (W)*498(D)*260(H) |
Gross.Weight
(KG) | ~10.4 |
| Accessory | | |
| | Manual Languages | Chinese,English |
| Standard Accessaries | Power cord(EU) /power cord(Ja)
Remote control&RC Battery |
